S675TC – Hot Tap Insertion Assembly for Use with S656 Series Sensors

$502.75

S675TC - Hot Tap Insertion Assembly for Use with S656 Series Sensors

Parameters & Applications

Product Information

Users installing into large tanks, large process lines and scrubber lines will appreciate this hot tap insertion assembly to simplify installation. Adjustable insertion depth up to 12” ensures sensor is in flow for best results. Designed in CPVC for a user friendly cost compared to expensive stainless models, the S675 assembly is well suited for most water and wastewater treatment applications. Incorporates optional automatic temperature compensation (ATC) with 1000Ω RTD. Supplied with 10 foot cable. Designed for use with our S656CD Flat Surface pH Cartridge and BV-1 Ball Valve to facilitate removal from system without need for shutdown.
  • Durable CPVC construction: Durable design suitable for most applications
  • Simple maintenance: Remove sensors for cleaning and maintenance without system shutdown
  • Easy installation: Mount in any orientation for ease of accessibility
  • One year limited warranty: We stand behind all our products with the Sensorex Guarantee
*Note: Sensor cartridge not included. Purchase S656 Cartridge Style pH Electrode for use with S675 Insertion Assembly. CA ResidentsProp 65 WARNING(S)

Users installing into large tanks, large process lines and scrubber lines will appreciate this hot tap assembly to simplify installation. Adjustable insertion depth up to 12” ensures sensor is in flow for best results. Designed in CPVC for a user friendly cost compared to expensive stainless models, the S675 assembly is well suited for most water and wastewater treatment applications. Incorporates optional automatic temperature compensation (ATC) with 1000Ω RTD. Supplied with 10 foot cable. Designed for use with our S656CD Flat Surface pH Cartridge and BV-1 Ball Valve to facilitate removal from system without need for shutdown.

  • Durable CPVC design is suitable for most applications
  • Remove sensors for cleaning and maintenance without system shutdown
  • Easy installation
  • One year limited warranty
Clear
SKU: S675TC Categories: ,

Additional information

Weight 1.33 lbs
Dimensions 19 × 3 × 3 in

Complete Your System


S656CD - pH Sensor Cartridge (Hot Tap, Insertion)

Users installing into large tanks, large process lines and scrubber lines will appreciate this flat surface self cleaning hot tap…

Add to Cart | $210.50

BV1 - Ball Valve, Full Port 1" CPVC

Our BV-1 full port 1” CPVC ball valve is designed for use with our S675 Series Wet Tap Insertion Assemblies and…

Add to Cart | $94.40
